It's past midnight and there's a $234 saw blade sitting in my cart. Forrest's Ultra Thin Kerf Woodworker II, forty teeth, .080" kerf, straight from Forrest. Gorgeous. Costs more than most of the tools in this apartment.
Then I go read what SawStop puts in its Professional Cabinet Saw manual: "Do NOT use a blade with a kerf less than 0.093" - 0.138"."
So on that saw, that blade — the expensive one, the one everybody in the forums genuflects toward — is a no. Not "suboptimal." Not "you'll get a little deflection." A no, from the company that built the machine. And the reason has nothing to do with tooth count, hook angle, or what grade of carbide is brazed on the tips. It's a fit problem. Nobody writes about it. Let's write about it.
Three You Choose, One You Have To Match
Tooth count, hook angle, carbide grade: those are preferences. Pick wrong and you get burn marks, tearout, a slow feed, a blade you don't love. Annoying. Recoverable.
Blade body thickness — the plate, the steel disc the teeth are stuck to — is not a preference. It's a fit-and-safety dimension, and the part it has to fit is your riving knife.
SawStop's Compact Table Saw manual says it in one sentence: "Note that the riving knife is thicker than the blade plate (the body of the blade) but not as thick as the kerf." That's a sandwich. Knife thicker than the plate, thinner than the slot the teeth cut. Too thin and the knife can't hold the kerf open behind the blade, which is the entire job of the thing. Too thick and it binds.
Federal law says the same thing, badly. OSHA's 1910.213(e)(2), for circular resaws, wants a spreader "slightly thinner than the saw kerf and slightly thicker than the saw disk" — both bounds. But 1910.213(c)(2), the section that actually covers hand-fed ripsaws, which is what a table saw is, only requires the spreader be "thinner than the saw kerf." The floor just isn't there. Manufacturers supply it. And as Shark Guard points out, OSHA isn't governing my second bedroom anyway. Nobody's inspecting me. That's exactly why I have to inspect me.
The Spec Is Stamped on the Knife, Not on the Sales Page
Here are SawStop's actual numbers from the Professional Cabinet Saw manual, and this is the part worth internalizing: blade plate 0.071"–0.083", blade kerf 0.093"–0.138", riving knife and spreader 0.090" thick. Blade-to-knife gap 0.175"–0.31". The manual also wants blades meeting EN 847-1, alignment within 0.010", arbor runout inside 0.001", and no blades with shoulders, because a shoulder "could prevent the brake pawl from effectively engaging the blade."
But the phrase that matters most is this one: use blades conforming to the specs "marked on the riving knife included with your saw." SawStop is telling you straight up that the authority is the physical part in your machine, not a manual, and definitely not me. Different knives carry different ranges. The Compact saw's plate window is 0.071"–0.087" — wider ceiling than the cabinet saw's 0.083", same brand.
Two more proofs that this is a fit spec and not a vibe. Grizzly sells a separate thin-kerf riving knife, the T33448, 2mm thick, requiring a 1.8mm blade body and a 2.2mm kerf, 10" blades only. That accessory exists because the stock knife is too fat for thin-kerf blades. And Harvey sells two knives for the same saws: a 0.086" thin knife at $42.99 rated for 0.094"–0.118" kerfs, and a 0.100" standard knife for 0.102"–0.126" kerfs. One saw. Two knives. The blade you buy decides which one belongs in the machine. Infinity goes further — its 1/16"-kerf Laser Kerf blade ships with its own matched TKS-001 splitter at $179.90, because no normal knife is thin enough to live in that slot.
Now run published blade specs against a 0.090" knife and a 0.071"–0.083" plate window. This arithmetic is mine, not any manufacturer's statement:
| Blade | Kerf | Plate | Against a 0.090" knife |
|---|---|---|---|
| Diablo D1050X 50T, $42.97 (The Power Tool Store) | .098" | .071" | Both inside the window |
| Amana PR1040 40T, $102.23 (ToolsToday) | .134" | .102" | Kerf passes. Plate doesn't |
| Infinity 010-050 50T, $99.90 | 1/8" | .103" | Plate outside |
| Ridge Carbide TS2000 40T, $144.95 (Incremental Tools) | .125" | .094" | Plate thicker than the knife |
The Amana is the teaching case. The spec everybody quotes — kerf — passes clean. The spec nobody checks fails by a mile. Meanwhile a $41 Diablo D1024X, .098" kerf on a .071" plate per CS Hardware, is dimensionally compliant. Price is not the variable here.
Hear me clearly: this is not "your Forrest is unsafe." Toolbox Trends reports the full-kerf Woodworker II at a 0.090" plate — Forrest doesn't publish plate thickness anywhere I could find, so treat that number as one review site's, not a factory spec. And SawStop sells more than one knife and explicitly defers to what's stamped on yours. The takeaway isn't an accusation. It's a habit: caliper the blade, read the knife, confirm the sandwich.
Why care? The CPSC's 2007–2008 survey estimated 79,500 emergency-room table and bench saw injuries. Blade contact caused 88.0% of operator injuries. Stock kicked back or jumped in 40.5% of cases. A riving knife was attached in 20.4%. An owner's manual was in the operator's possession in 64.1% — a third of injured operators didn't have the document carrying the numbers.
Bite, Chip Room, and How Much Motor You've Got
Hook angle is bite. Carbide Processors puts 20° positive on rip blades "to pull the wood into the blade," calls 18°–22° most effective for ripping and softer materials, and reserves –5° negative for stopping self-feed on sliding miters and radial arms. Real blades cluster: Forrest 20°, Amana PR1040 18°, Diablo 15°, Infinity's combo 12°.
Note what a positive hook does. It pulls the work in. That's precisely the force the riving knife exists to manage, which is why hook angle and knife fit aren't separate subjects. A 20° hook with a mismatched knife is the worst pairing in this article.
Tooth count is chip room, not smoothness. Per ToolsToday, rip blades run 24T with big gullets to haul chips out; crosscut blades run 60–80T and want a slower feed because each tooth takes less. Combos split it — Infinity's 50T uses an ATB-R grind, four 15° ATB teeth plus a chamfered raker; Ridge's 40T runs 15° ATB plus eight flat rakers.
Thin kerf is a horsepower decision. Forrest recommends its 3/32" thin kerf for 1.5 HP and under, 1/8" for 1.75 HP and up. Infinity points its thin-kerf combo at saws under 3 HP. Woodcraft notes thin kerf keeps small benchtop motors from bogging. And Forrest strongly recommends a 4" or 5" stiffener when ripping hardwoods with the .080" blade — but understand what a stiffener does. It clamps one face and reduces flex. It changes neither kerf nor plate. It cannot fix a knife mismatch.
"C-4" Doesn't Mean What The Box Wants You To Think
Everybody's marketing leans on carbide grade. Forrest: "double-hard C-4." Ridge Carbide: "Micro Grain C-4." Infinity: "C4 sub-micron."
Carbide Processors blew this up in their own blog: "A C-1, C-2, C-3, and so on, has absolutely nothing to do with hardness, toughness, cobalt percentage, grain size or anything else." The designations are 1940s production identifiers. The classes describe jobs — C-1 roughing, C-2 general purpose, C-3 finishing, C-4 precision — and there is no straight progression from C-1 to C-14.
Tom Walz, the company's president, told Woodshop News there are at least 5,000 grades of tungsten carbide sold under more than 1,500 trade names by more than 1,500 companies, and that the numbering "leads one to believe that the higher C number is harder... This is like classifying automobiles by size from a moped to an 18-wheel semi." Two identical C-7 tips from two suppliers will almost certainly behave differently.
So "C-4" tells you an intended application class, not a material, and it doesn't compare across brands. Amana doesn't even play — it calls its tips proprietary D-10. What is checkable is tip size, because bigger tips mean more sharpenings. Freud markets the P410 Premier Fusion, a .126" Hi-ATB at $113.99 from Woodcraft, on exactly that: larger carbide tips for more resharpening. That's a claim you can look at.
Sharpen It Or Toss It: The Three-Times Rule
Before you condemn anything, clean it. Woodcraft's line is the one I repeat: burning on both sides of the cut means swap the blade, but check for pitch first — you may find "still-sharp teeth hiding under a layer of baked-on residue."
If it's genuinely dull, do the math. Freud's factory service is $19 for a 10" under 40 teeth, $22 at 40 teeth or more, with tooth runout held to .002". Forrest's 2026 list is $32 for 32–40 teeth through 12", $35 for 42–60, plus $16 return shipping on the first blade, two-week turnaround, tips replaced at $9/$6/$5 depending on count. Ridge Carbide charges $20 for 25–40 teeth, $23 for 41–60, $13 return shipping, $7 a tip. A local shop like Bob's Sharp All runs $0.40 a tooth under 80 teeth — a 40T is sixteen bucks, no shipping.
Now the crossover:
- Diablo D1050X, $42.97 new, $22 to sharpen at Freud. That's 51% of a new blade before shipping either direction. Buy the new one.
- Ridge Carbide TS2000 40T, $144.95 new, $20 + $13 shipping = $33. About 23%. Sharpen it.
- Forrest Woodworker II 40T, $169.99 at The Woodsmith Store up to $195 at Rockler, $32 + $16 = $48. Roughly a quarter. Sharpen it, every time.
- Amana PR1040, $102.23 on sale, $16 at a local shop. 16%.
My rule: sharpening pays when the blade costs more than about three times the sharpening charge. Under sixty, seventy bucks a blade, the round trip plus two to three weeks of downtime loses to a new blade off the shelf. Over a hundred, it's not close, and the blade was built for it.
How many times can you sharpen? Ridge Carbide's vendors claim "20-25 times" in one listing and "20 times" in another. Those are marketing, they contradict each other, and I wouldn't build a plan on them.
The Blade Retires Before It Stops Cutting
Here's where the two halves of this article collide, and this next bit is my reasoning, not anybody's published rule.
Every sharpening narrows the kerf. Amana's VP of sales and marketing, John McInerney, told Woodworker's Journal that "after multiple resharpenings, the side clearance gets diminished as it approaches the thickness of the plate" — at which point the shop can only face-grind, and it's time to buy. Shark Guard says to micrometer tooth width specifically because tapered teeth change kerf thickness after sharpening.
Your riving knife thickness never changes. SawStop's is 0.090". Grizzly's thin-kerf accessory is 2mm. Harvey's two are 0.086" and 0.100".
So a blade's retirement date isn't "when it stops cutting well." It's when the kerf has narrowed far enough that it no longer clears the knife with margin. On a saw with a 0.090" knife and a stated 0.093" kerf floor, a blade that left the factory at .098" has about .005" of kerf to give away across its entire sharpening life. Even brand new at the floor, 0.093" around a 0.090" knife is .0015" a side. Half a sheet of paper.
No source I could find prints that retirement criterion, and it's checkable for thirty bucks. Do it the day a blade comes back from sharpening, every time, and write the number on the blade's sleeve with a marker.
Two habits, that's all I'm asking. Read what's stamped on your riving knife before you buy a blade. Measure the kerf after every sharpening. The blade you already own is the tool you're most likely to be careless with.
