Somewhere on a woodworking forum right now, someone is explaining that they rewired their table saw for 240 volts and it runs stronger. More torque, faster spin-up, no bogging down in 8/4 maple. The reply below calls it a myth. The reply below that quotes an electrician who swears by the swap. Forty posts later, nobody has read a nameplate.
I run a hybrid shop in Seattle, CNC router on one side, cabinet saw and hand tools on the other, in a space that smells like wet fir half the year, and the wiring question has never been academic for me. So let's settle it the way I'd settle any shop decision: with motor nameplates, the electrical code, and published electrician prices. The short version is that 240V buys something genuinely valuable, but not what the forum post claims. It buys headroom, not horsepower, and the distinction decides where your money goes.
Two Windings, One Horsepower
A dual-voltage (120/240V) motor contains two 120-volt windings. Matthias Wandel's writeup at woodgears.ca lays out the arrangement: wired for 240V, the windings connect in series; wired for 120V, in parallel. Each winding sees 120 volts either way. The motor cannot tell the difference.
Victory Motor, a manufacturer of these things, states it without hedging: "No matter the voltage, the motor delivers the same horsepower (HP) or kilowatt (kW) rating." The only variable is current, roughly halved at the higher voltage. An engineering thread on Physics Forums (forum posts, so weigh them accordingly) lands in the same place: performance and torque are essentially identical at either connection, and 240V's benefit is lower current in the walls and plugs, which as one contributor put it has "nothing to do with the motor." The same thread notes that capacitors and bearings fail long before windings do, at either voltage.
You can watch this play out on a single machine. JET's spec page for the DC-1100VX dust collector lists one 1.5HP motor moving 1,100 CFM at the 4" inlet, drawing 11 amps at 115V or 5.5 amps at 230V. Same machine, same airflow, same horsepower. Only the current changes.
One caution before you open a wiring box: Wandel warns that a dual-voltage motor connected wrong will draw about 100 amps without running, and can start to smoke within ten seconds. Follow the motor-plate diagram, and verify with an ohmmeter if the leads are ambiguous.
The Nameplate That Ends the Argument
Here is the comparison I keep coming back to, straight from Woodcraft's listings. SawStop's 1.75HP Professional Cabinet Saw runs on 110V and draws 14 amps. SawStop's 3HP Professional Cabinet Saw runs on 230V and draws approximately 13 amps. The bigger saw pulls fewer amps, because it gets to multiply those amps by twice the voltage.
That is the whole story in two nameplates. Voltage does not make a motor stronger; voltage headroom is what lets a stronger motor exist on a household circuit at all. Tool Nut lists SawStop's 5HP Industrial saw at 19.7 amps on 230V; run that backward to 115V and you get roughly 39 to 40 amps (my arithmetic, not a spec sheet), beyond any standard 15 or 20 amp receptacle circuit. That is why nobody sells a 5HP 120V cabinet saw.
The same discipline sorts out horsepower marketing. Hanes Supply lists the DeWalt DW735 planer as "2 hp"; other listings say 1.5HP. The machine is 120V-only and draws 15 amps, and 15 amps at 120 volts is 1,800 watts of input, full stop. Amps are the number that never lies; on 120V tools, ignore the horsepower on the box.
The verified figures, prices as fetched this July:
| Machine | HP | Voltage | Amps | Price (retailer) |
|---|---|---|---|---|
| SawStop PCS 1.75HP | 1.75 | 110V | 14A | $3,025 (Woodcraft) |
| SawStop PCS 3HP | 3 | 230V | ~13A | $3,881 (Woodcraft) |
| SawStop ICS 5HP | 5 | 230V | 19.7A | $5,822 (Tool Nut) |
| Jet DC-1100VX | 1.5 | 115/230V | 11A / 5.5A | $758.99 (Rockler) |
| DeWalt DW735 | contested | 120V only | 15A | $769 (Hanes Supply) |
The Code Doesn't Care About Your Voltage
The part of this argument almost nobody gets right is the wire. NEC Table 310.16, summarized in EleCalculator's ampacity guide, pairs copper conductors with the current they carry: 14 AWG handles 15 amps, 12 AWG handles 20, 10 AWG handles 30. Read that table closely and notice what's missing: voltage. A 12 AWG conductor is a 20-amp conductor whether it carries 120V or 240V.
The practical consequence is the cheapest good news in this subject. Converting a circuit from 120V to 240V at the same amperage reuses the exact copper already in your walls; what changes is the breaker, now a 2-pole, and the receptacle. Yet that same 12 AWG wire delivers 4,800 watts at 240V against 2,400 at 120V, double the power through the same copper, by nothing fancier than W = V × A. More striking still: the 3HP SawStop ships with a NEMA 6-15 plug per its manual, a 240V/15A circuit, which is 14 AWG wire, the same gauge feeding a bedroom lighting circuit. "Rewiring for 240" sounds industrial. Electrically, it's modest.
The code also explains why your 120V circuit feels crowded. JADE Learning's explainer on NEC 210.23(A)(1) covers the 80% rule: no single cord-and-plug tool may exceed 80% of the branch circuit's rating. On a 20A circuit that is a 16-amp ceiling for any one machine. The DW735 at 15 amps clears the bar, barely, and in doing so effectively owns the entire circuit.
The Simultaneity Problem
Which brings us to the argument's real substance, because a one-person shop rarely runs one motor at a time. The machine cutting and the dust collector pulling chips run together, always.
Add the verified nameplates yourself. The DW735 at 15 amps plus the Jet collector at 11 amps in its 115V wiring totals 26 amps on what is probably a 20-amp circuit: a 30% overload that will trip the breaker mid-board. The 1.75HP SawStop at 14 amps plus the same collector is 25 amps. Neither pairing fits on one circuit. This, not motor performance, is the wall a growing 120V shop actually hits.
Now run the 240V version. Flip the Jet's motor to 230V and it draws 5.5 amps. Pair it with the 3HP saw at roughly 13, and the two machines together pull 18.5 amps, spread across two 240V circuits. Your whole working pair demands less current than the planer-and-collector combination did at 120V. To be precise about the wiring: Woodcraft's listing calls for a dedicated 230V circuit for the saw, so this is not about doubling machines up on one outlet. It's about what your panel carries with ease instead of at its limit.
What the Invoice Says
None of this matters until an electrician prices it. Zimmerman Electric, a licensed Indianapolis shop that publishes its rates, puts a single 240V garage outlet at $400 to $800 installed, their 2025 estimates, with permit and inspection fees of $50 to $150. If your panel has no spare capacity, they price that work at another $1,000 to $2,500.
For a whole-shop solution, InstaElectricians' 2026 cost guide puts a 60-amp garage subpanel at $500 to $900, a 100-amp at $700 to $1,200, and an attached garage at $500 to $1,500 all-in. A detached shop changes the math: $1,500 to $4,000 or more, with the underground feed alone at $10 to $25 per linear foot. A main service upgrade first adds $1,500 to $3,500; a full panel replacement runs $4,000 to $8,000.
Notice what isn't driving those numbers: copper. Wire & Cable Your Way sells 12/2 NM-B at $0.89 a foot, which prices the wire for a typical 40-foot machine circuit around $36. Labor is the bill. And since an equal-amperage 240V conversion keeps the same gauge, the voltage itself adds nothing to the wire cost. The step that does cost more is amperage. Penn Tool Co. lists the Powermatic 15HH planer, a 3HP 230V machine with no 120V version, at $4,570.95 plus $195 freight and a recommended 30-amp circuit, and 30 amps means 10 AWG at $1.56 a foot, about 1.75 times the price of 12 gauge.
Three Bins, One Decision
I've come to believe the useful move is sorting your tools into three bins before calling anyone.
Genuinely needs 240V: the 3HP-and-up cabinet saws and 15" stationary planers. SawStop's 3HP and 5HP saws are 230V only; the Powermatic 15HH is 230V only. These machines don't exist at 120V because their current draw wouldn't fit a receptacle circuit.
Dual-voltage, same performance either way: the Jet DC-1100VX, or WEN's BA1411 band saw at $1,049.99, which runs its one 11-amp, 1HP motor at either voltage; WEN's own page promises versatility from the switch, not power. Converting these buys the machine nothing. It buys your panel 11 amps of 120V breathing room, which may be worth more.
Gains nothing, no option exists: the universal-motor lunchbox class. The DW735 is 120V-only with no 240V variant, and that pattern broadly holds for routers and sanders. Rewiring the shop does nothing for these tools except stop them from sharing a circuit with something else.
The question was never whether 240 gives your saw more power. It's what your panel has to carry at 4:30 on a Friday with the saw spinning and the collector pulling. Before you call an electrician, spend twenty minutes with a flashlight reading nameplates and sum the amps of everything that runs at once. If the sums fit your breakers, keep the money in lumber. If they don't, price one dedicated 240V circuit before you price a subpanel; at $400 to $800 against $1,500 and up for a detached feed, the smaller job solves most one-person shops.
